SR7508 JUMBO
High-tech 15-speed machine, with a maximum drilling diameter of 900mm.
| JUMBO MODEL | SR7508 | SR75S/SR7508S |
| Nominal voltage | 400-3V | 400-3V |
| Rated current | 15A | 15A |
| Nominal power | 7500W | 7500W |
| Effective power | 5700W | 5700W |
| Gears 1/min | 60*/70*/85/100/115
115*/140*/165/200/230 180*/215*/260/310/360 |
75*/90*/105/130/150
150*/175*/210/250/290 230*/280*/330/390/460 |
| Length | 620 mm | 620 mm |
| Weight | 19,5 kg | 19.5 kg |
| Drilling in concrete | Ø150-900 | 120-800 |
| hitch | M33/3 | 1 ¼” UNC / M33/3 |
* These gears have reduced speed
