DM62 2-speed dry drilling motor
A 2000 W high speed motor and 2 speeds for dry drilling of reinforced concrete up to 162 mm and standard dry drilling up to 262 mm.
Excellent for overhead drilling, operation in sub-zero temperatures and any situation where water cannot be used. Dust extraction through the spindle and switchable soft percussion allow for optimum dry drilling performance.
- Specially designed for dry drilling of reinforced concrete.
- Magnesium alloy motor housing for minimum weight and maximum strength.
- Switchable soft percussion for optimized dry drilling
- LED indicator light to optimize drilling efficiency with overload and overheat warning
- Built in vertical and horizontal levels for accuracy
- Dust extraction port for efficient dry drilling
| Power | 2200W |
| Voltage, frequency | 220-240 ~ 50-60Hz |
| Capacity | Dry (brick) – Ø262 mm
Dry (reinforced concrete) – Ø162 mm |
| No load / min. rated load speed | Speed 1: 1250 / 750
Speed 2: 1900 / 1140 |
| Percussive frequency (no load/full load) | Speed 1: 25000 bpm / 15000 bpm
Speed 2: 38000 bpm / 22800 bpm |
| Spindle thread | 1 ¼”UNC and ½” BSP |
| Neck diameter | Ø60 mm |
| Dimensions (LxWxH) | 430 mm x 122 mm x 190 mm |
| Weight | 6.2 kg |
